Hella Marine 3085 High Capacity 24V 60A Relay

Hella Marine High Capacity 24V 60A Relay (Part Number: 3085)

The Hella Marine 3085 is a heavy-duty, 24V DC 60-Amp High-Capacity Single Pole Single Throw (SPST) power relay engineered to control high-current electrical loads aboard vessels, commercial craft, and heavy-duty 24V mobile machinery. Designed to handle continuous switching for high-draw DC equipment—such as electric anchor windlasses, thrusters, high-output marine pumps, halogen floodlights, and horn systems—it allows low-current helm switches to actuate heavy power circuits safely.

Encapsulated in an impact-resistant, non-corrosive composite housing with an integrated metal mounting bracket, the 3085 relay features heavy-gauge silver alloy internal contacts to prevent contact arc welding and pitting under high inductive loads. Fitted with standard 6.3 mm (1/4") and oversized 9.5 mm high-power spade terminals, it delivers low voltage drop and cool operation across continuous duty cycles.

Key Features

• 60A Continuous Switching: Safely manages high-current DC motor loads, marine pumps, and high-wattage lighting arrays.

• Heavy-Duty Silver Alloy Contacts: Resists arcing, pitting, and oxidation under high inductive voltage surges.

• Integrated Metal Mounting Bracket: Allows firm bolt-down installation inside engine room control panels and distribution boxes.

• Corrosion-Proof Composite Enclosure: Durable housing protects internal coil and contacts against marine salt air and humidity.

• Dual Blade Terminal Sizes: Features standard 6.3 mm coil terminals and high-current 9.5 mm load terminals for secure spade connections.
