BEP 184100P-01-1 Heavy-Duty 100A Panel Mount Circuit Breaker

BEP Heavy-Duty 100A Panel-Mount Circuit Breaker (Manual Reset)

The BEP 184100P-01-1 (OEM platform Bussmann 184 Series / Hi-Amp) is a heavy-duty, high-amperage 100 Amp panel-mount thermal circuit breaker engineered for primary main distribution, windlass, bow thruster, inverter power feeds, and heavy DC branch circuits. It functions as both a thermal circuit protector and an accessible DC main disconnect switch.

Designed with a Type III manual reset lever mechanism, the breaker allows operators to visually confirm a trip condition and manually reset or open the circuit. Built into a weatherproof thermoset plastic housing with IP67 water resistance, it features heavy-duty 1/4" stainless steel stud terminals and SAE J1171 / ISO 8846 ignition protection, making it safe for installation in gasoline engine compartments and battery lockers.

Key Features

• Type III Manual Reset & Switch Operation: Visible red reset lever indicates a tripped state and doubles as a manual system disconnect switch.

• Ignition Protected (SAE J1171 / ISO 8846): Completely sealed contact chamber allows safe installation in engine rooms and battery compartments.

• Through-Panel Surface Mounting: Through-panel mounting flange allows clean dashboard or distribution panel installation with front-accessible reset lever.

• IP67 Waterproof Rating: Sealed enclosure withstands heavy sea spray, washdown water, and harsh marine environments.

• High Interrupt Capacity: Rated to interrupt high short-circuit currents up to 3,000A @ 30V DC, protecting primary DC bus systems.
