BEP 80-601-0021-00 24V Analog Voltmeter Panel

BEP Contour 24V Analog DC Voltmeter Panel (80-601-0021-00)

The BEP 80-601-0021-00 is a panel-mounted 3-Input 24V DC Analog Battery Condition Voltmeter engineered for monitoring 24 V DC marine power distribution networks and battery banks. Featuring a moving-coil meter with an expanded scale (16 to 32 V DC), it provides high-resolution voltage tracking across critical operational thresholds, making small state-of-charge fluctuations easy to read at a glance.

Housed on a black powder-coated aluminum panel with BEP Contour Series styling, the unit incorporates an integrated 3-position selector switch. This allows operators to toggle instantly between three separate battery banks (such as House, Port Engine, and Starboard Engine banks) using a single analog gauge.

Key Features

• Expanded Scale Dial (16-32 V DC): Suppresses non-critical lower voltages (0-16 V) to maximize needle movement and legibility in the vital 24 V operating band.

• 3-Bank Selector Switch: Integrated 3-position rotary/rocker switch monitors up to 3 isolated battery banks through a single meter face.

• High Measurement Accuracy: Precision moving-coil movement factory calibrated to within ± 2.5% full scale.

• Contour Series Panel Matching: Designed with matching dimensions, powder-coated finish, and bezel contours to blend seamlessly into BEP circuit breaker panels.
