BEP 80-601-0024-00 0-50A Analog DC Ammeter Panel

BEP Contour 0–50A Analog DC Ammeter Panel (80-601-0024-00)

The BEP 80-601-0024-00 is a marine-grade 3-Input 0–50A DC Analog Ammeter Panel designed for real-time electrical load and charge monitoring across vessel power systems. Featuring a moving-coil dial calibrated across a 0 to 50 A DC scale, it provides high-contrast, analog current tracking for alternator output, solar charge systems, or DC distribution circuits.

Built on a black powder-coated aluminum panel with BEP Contour Series styling, the unit includes an integrated 3-position selector switch. This allows operators to toggle between three independent DC current shunts across different circuits using a single meter face. The unit comes supplied with one 50A / 50mV DC resistive current shunt.

Key Features

• 0-50 A DC Linear Scale: Provides clear, real-time current draw and charging readouts up to 50 A.

• 3-Input Selector Switch: Allows a single panel gauge to monitor up to three separate DC circuits via external ammeter shunts.

• Includes 50A / 50mV Shunt: Supplied complete with one resistive current shunt for immediate installation on the primary monitored circuit.

• Contour Series Panel Matching: Designed with identical dimensions and black powder-coated finish to seamlessly match BEP Contour circuit breaker modules.
