BEP CBS-15A-SP Contour 15A Single Pole Circuit Breaker

BEP Contour Series 15A Single-Pole Hydraulic-Magnetic Circuit Breaker

The BEP CBS-15A-SP is a marine-grade 15 Amp single-pole hydraulic-magnetic circuit breaker (IEG platform) engineered specifically for integration into BEP Contour series AC and DC electrical distribution panels. Operating as both a resettable protective device and a panel toggle switch, it provides precise circuit control for branch distribution circuits such as cabin lighting, navigation instruments, pumps, and electronics.

Unlike standard thermal breakers whose trip thresholds fluctuate with engine room heat, the CBS-15A-SP utilizes sensitive hydraulic-magnetic sensing technology that remains completely stable across temperature extremes. It incorporates a "trip-free" safety mechanism that forces the internal contacts to open during an electrical fault even if the external toggle actuator is manually held in the ON position.

Key Features

• Temperature-Stable Hydraulic-Magnetic Operation: Trip threshold is unaffected by ambient panel heat or cold weather variations.

• Trip-Free Safety Mechanism: Prevents holding the breaker ON against a sustained fault condition to protect wiring insulation.

• Direct BEP Panel Compatibility: Mounts seamlessly into BEP Contour AC and DC marine switchboards and custom console panels.

• Dual AC/DC Voltage Capability: Rated for both 32V DC low-voltage distribution and up to 250V AC sub-panel circuits.

• Screw Terminal Connections: Heavy-duty screw terminals provide vibration-proof wire terminations for stranded marine primary cable lugs.

Specifications
