BEP CBS-20A-SP Circuit Breaker 20A SP

IEG magnetic circuit breakers provide reliable circuit protection and accurate circuit control for equipment in the international market place. Designed using the latest in sensitive hydraulic magnetic technology, the IEG line adapts itself to many applications and environments. They are ideal for marine applications, data processing and business machines, as well as medical instrumentation, broadcast equipment, vending and amusement machines, military applications and wherever precision operation is required. Temperature differences which affect fuses and other thermal devices are not a concern. One important feature of this breaker line is a 'trip free' action, which means the circuit will trip in the presence of an overload even though the handle is held in the ON position. The delay mechanism senses the fault and the contacts open.

Key Features

• Hydraulic-Magnetic Trip Technology: Delivers accurate overload protection unaffected by ambient temperature changes in hot engine rooms or sealed panel enclosures.
• Dual AC/DC Voltage Capability: Universal design rated for both 250V AC and 65V DC branch circuit protection.
• Nuisance Trip Resistance: Magnetic delay curve accommodates momentary high-inrush currents from motors and inductive loads without false tripping.
• Compact Marine Panel Standard: Industry-standard small-frame footprint compatible with BEP Contour, Blue Sea Systems, and custom marine panels.
• Corrosion-Resistant Components: Constructed with stainless steel hardware and non-corrosive materials for long life in salt-air environments.
