BEP IP200 Ignition Protected 200A ANL Fuse

BEP 200A Ignition Protected ANL Fuse (IP Certified)

The BEP IP200 (cataloged as IP200A or IP200P/DSP) is a heavy-duty 200 A Ignition Protected ANL circuit protection fuse designed for main DC distribution, high-output alternator feeds, inverter banks, and anchor windlass circuits. Certified to SAE J1171 and ISO 8846 ignition protection standards, this fuse is safe for installation in gasoline engine compartments, fuel tank spaces, and enclosed battery lockers where flammable gases may accumulate.

Constructed with high-conductivity, tin-plated copper blade terminals, the IP200 resists corrosion, oxidation, and pitting in harsh saltwater environments. It features a time-delay (slow-blow) characteristic that accommodates temporary, high inductive motor in-rush currents (e.g., windlass or thruster activation) without false tripping, while opening rapidly during sustained overloads or short-circuit faults. An integrated clear inspection window allows rapid visual verification of element status.
