Blue Sea Systems 1484-BSS 230V AC 30A Rotary Switch

Blue Sea Systems 360 Panel 230V AC 30A Rotary Source Selector (1484-BSS)

The Blue Sea Systems 1484-BSS (catalog number 1484) is a professional 230V AC 30A rotary source selector switch module built on the modular 360 Panel distribution system platform. Designed to safely manage multiple AC inputs—such as switching between shore power and an onboard generator or inverter—it prevents simultaneous connection of live AC sources.

The panel features a heavy-duty rotary switch with an OFF + 2 Sources detent mechanism. It integrates dual Green "Power Available" status LEDs alongside dual Red "Reverse Polarity" warning LEDs for each AC channel. Constructed with an industrial-grade polycarbonate faceplate, this compact panel fits standard 360 series cutouts, providing safe, arc-isolated AC source management for European and international 230V marine and mobile power systems.

Key Features

• Break-Before-Make Contacts: Prevents dangerous back-feeding or phase short-circuits by ensuring line 1 completely disconnects before line 2 connects.

• Dual LED Monitoring System: Green LEDs indicate AC voltage presence; Red LEDs warn instantly of hazardous reversed live/neutral polarity.

• 360 Panel Modular System: Features snap-in modular frame architecture for clean integration into custom 360 distribution boards.

• Compact Rear Footprint: Shallow depth profile behind the mounting surface leaves ample room for heavy 230V conductor routing.

• Flame-Retardant Panel Housing: Constructed from reinforced, self-extinguishing thermoset polymer materials.
