Blue Sea Systems 2300 10-Gang 150A Common BusBar with Cover

Blue Sea Systems 10-Gang 150A Common BusBar with Cover (2300-BSS / 2300)

The Blue Sea Systems 2300-BSS (Catalog SKU: 2300 / 2300B-BSS) is a compact, high-density 10-Gang Common BusBar with Insulating Cover engineered for centralized DC positive distribution, negative return collection, or AC grounding arrays in marine, RV, and commercial power systems. Rated for up to 150 A DC continuous current, it consolidates branch circuits onto a single organized platform, eliminating clutter and potential short circuits behind electrical control panels.

Manufactured from high-conductivity tin-plated CDA 110 copper mounted on a flame-retardant glass-reinforced thermoplastic base, the assembly exhibits exceptional resistance to saltwater corrosion and high thermal stress. The module features ten #8-32 terminal screws for branch loads and two 1/4"-20 terminal studs for main feeder connections. It comes complete with a push-on clear polycarbonate insulating cover that satisfies ABYC and USCG safety standard requirements.

Key Features

• High-Density Wire Collection: Consolidates 10 separate branch circuit ring or spade terminals into a compact footprint.

• High-Conductivity Tinned Copper: CDA 110 / UNS 11000 tinned copper bar provides maximum electrical conductivity and environmental corrosion resistance.

• Dual Main Power Studs: Stainless steel 1/4"-20 terminal studs accept heavy-gauge main feed or battery return cables.

• ABYC / USCG Compliant Cover: Includes a press-on clear polycarbonate protective cover to guard against shorting and accidental contact.

• UL 94-V0 Rated Base: Glass-reinforced thermoplastic base provides self-extinguishing flame protection and high heat resistance.
