Blue Sea Systems 2302 20-Gang 150A Common BusBar

Blue Sea Systems 20-Gang 150A Common BusBar (2302-BSS / 2302)

The Blue Sea Systems 2302-BSS (Catalog SKU: 2302) is an industry-standard high-density 20-Gang Common BusBar engineered for centralized DC positive power distribution, negative return collection, or AC grounding arrays. Designed to handle up to 150 A DC continuous load, it eliminates dangerous wire cluster tangles and bridging cables behind control consoles and main power distribution panels.

Constructed from heavy-gauge tin-plated CDA 110 copper mounted onto a glass-reinforced, flame-retardant thermoplastic base, the busbar provides high electrical conductivity with resistance to marine atmospheric corrosion. It features twenty #8-32 terminal screws for branch loads alongside two 1/4"-20 terminal studs for main feeder line attachment.

Key Features

• High-Density Wire Collection: Consolidates 20 separate branch circuit ring or spade terminals onto a single compact busbar.

• High-Conductivity Tinned Copper: CDA 110 / UNS 11000 tinned copper bar ensures maximum current carrying capability and corrosion protection.

• Dual Main Power Studs: Includes two 1/4"-20 stainless steel terminal studs for heavy-gauge main feed or battery cable connections.

• UL 94-V0 Rated Base: Glass-reinforced thermoplastic mounting base provides exceptional thermal resistance and self-extinguishing flame protection.

• Cover Compatible: Accepts optional snap-on protective insulating covers (Blue Sea Systems PN 2716 or PN 2715) to meet ABYC/USCG insulation standards.
