Blue Sea Systems 2304 MiniBus 5 x #8-32 Common BusBar

Blue Sea Systems MiniBus 5-Position Common BusBar (2304-BSS / 2304)

The Blue Sea Systems 2304-BSS (Catalog SKU: 2304 / 2304B-BSS) is an ultra-compact MiniBus 5-Position Common BusBar designed for space-constrained DC power distribution, ground return collection, or electronics branching on boats, RVs, and custom electrical enclosures. Rated for up to 100 A DC continuous current, it consolidates small power or ground wires into a tidy, organized distribution hub.

Engineered with high-conductivity tin-plated CDA 110 copper mounted on a flame-retardant glass-reinforced thermoplastic base, the 2304 resists harsh marine oxidation and thermal stress. The module features five #8-32 screw terminals for branch load ring or spade connections, providing maximum electrical reliability in a minimal footprint.

Key Features

• Ultra-Compact Footprint: Fits into extremely tight console spaces, electronics boxes, and sub-panels.

• High-Conductivity Tinned Copper: CDA 110 / UNS 11000 tinned copper bar provides maximum electrical conductivity and marine corrosion resistance.

• 100A Continuous Rating: Handles substantial current loads despite its miniaturized physical dimensions.

• UL 94-V0 Rated Base: Glass-reinforced thermoplastic base provides self-extinguishing flame protection and high heat resistance.

• Cover Compatible: Compatible with optional protective insulating cover (Blue Sea Systems PN 2708) to satisfy ABYC and USCG insulation requirements.
