Panel enclosure for ELCI Main circuit breakers and other large frame devices. Meets ABYC E-11 when used with an ELCI Main circuit breaker and mounted within 10 feet of the shore power inlet

• Includes one 120V AC / 30A ELCI Main and three blank positions
• Blank apertures for custom breaker loading
• Glass filled polycarbonate mounting box
• Clear cover allows easy view of circuit breaker status
• Overlapping cover for strength and increased gasket protection
• Oversized, formed in place seamless PUR gasket
• Easily removable stainless steel hinge pin for unobstructed installation
• Stainless steel latch secures cover without penetrating the enclosure
• Blank circuit positions accommodate Carling Technologies™ A- and C- Series Flat Rocker and ELCI Main circuit breakers
• Stainless steel mounting hardware included
• Includes waterproof glands
• LED lights for back lighting and ON indication



Specifications
Minimum Operating Temperature	-35° C
Maximum Operating Temperature	66° C
Cover Screws and Hardware	10-32 Stainless Steel
Enclosure Size	6.0" x 6.0" x 4.0" (152mm x 152mm x 102mm)
Exterior Overall Dimensions	7.6" x 7.4" x 4.7" (192mm x 188mm x 120mm)
Mounting Hardware	1/4" Diameter, #12 (6 mm)
Weight	7.00lb (3.18 kg)
