Blue Sea Systems - 3120-BSS - Enclosure SMS Panel 240VAC ELCI 50A

  • $ 825.21 USD

SMS Surface Mount System Panel Enclosure - 240V AC / 50A ELCI Main - For Isolation Transformer


Panel enclosure for ELCI Main circuit breakers and other large frame devices. Meets ABYC E-11 when used with an ELCI Main circuit breaker and mounted within 10 feet of the shore power inlet
  • Blank apertures for custom breaker loading
  • Glass filled polycarbonate base
  • Clear cover allows easy view of circuit breaker status
  • Overlapping cover for strength and increased gasket protection
  • Oversized, formed in place seamless PUR gasket
  • Easily removable stainless steel hinge pin for unobstructed installation
  • Stainless steel latch secures cover without penetrating the enclosure
  • Blank circuit positions accommodate Carling Technologies™ A and C Series Flat Rocker and ELCI Main circuit breakers
  • Stainless steel mounting hardware included
  • Includes waterproof glands
  • Green LEDs for backlighting and ON indication


Minimum Operating Temperature -35° C
Maximum Operating Temperature 66° C
Cover Screws and Hardware 10-32 Stainless Steel
Enclosure Size 6.0" x 6.0" x 4.0"
(152mm x 152mm x 102mm)
Exterior Overall Dimensions 7.6" x 7.4" x 4.7"
(192mm x 188mm x 120mm)
Mounting Hardware 1/4" Diameter, #12 (6 mm)
Weight 4.00lb (1.81 kg)
