Blue Sea Systems - 7086-BSS - Circuit Breaker Buss 285 Panel 80A

Blue Sea Systems - 7086-BSS - Circuit Breaker Buss 285 Panel 80A

USD $69.52 USD
USD $69.52 USD USD $69.52 USD
Sale Sold out
Shipping calculated at checkout.

285-Series Circuit Breaker - Panel Mount 80A

7086

  • Drop in replacement for 185-Series Circuit Breakers
  • Visible reset lever shows open condition
  • Ignition protected - Safe for installation aboard gasoline powered boats
  • Meets SAE J1171 external ignition protection requirements
  • Weather Resistant
  • Combines switching and circuit breaker function into one unit*
  • "Trip Free" - cannot be held closed after trip
* Do not use as a switch where high inrush currents are expected.
Specifications
Amperage 80A
Maximum Voltage 48V DC
Mounting Panel Mount
Circuit Breaker Type Thermally responsive Bi-metal blade
Terminal Stud M6 (accepts 1/4" Ring Terminal)
Terminal Stud Torque 50 in-lb (5.65 Nm)
Interrupt Capacity  3000A @ 48V
Minimum Operating Temperature -40° C
Maximum Operating Temperature 85° C
Circuit Breaker Class Type III - switchable/manual reset - trip free
Weight 0.50lb (0.23 kg)
