7142B-BSS

Blue Sea Systems - 7142B-BSS - Breaker Thermal 187 SrfcMnt 80A (FLM- 5)

  • $ 80.18 USD


    • Combines switching and circuit protection into a single device*
    • Clear, single lever operation
    • "Trip Free" design cannot be held "ON" during fault current condition
    • Waterproof
    • Recessed mounting holes for clean appearance
    • Large Clearance around terminal studs accept heavy gauge wire lugs
    • Robust 5/16 M8 terminals provide high torque connections
    • Large lever with vertical/horizontal orientation provides indication of trip status
    • Ignition protected - Safe for installation aboard gasoline powered boats
    • Meets SAE J1171 external ignition protection requirements

    * Do not use as a switch where high inrush currents are expected.
Specifications
Amperage 80A
Maximum Voltage 48V DC
Mounting Surface Mount
Circuit Breaker Type Thermally responsive Bi-metal blade
Terminal Stud Torque 75 in-lb (8.47 Nm)
Interrupt Capacity  5000A @ 12V
3000A @ 24V
1500A @ 42V
Minimum Operating Temperature -40° C
Maximum Operating Temperature 85° C
Case Material Thermoset Polyester
Circuit Breaker Class Type III - switchable/manual reset - trip free
Mounting Hole Accept #10 (M5) Screw
Terminal Stud Size 5/16" - 18
Weight 0.58lb (0.26 kg)
