Fischer Panda 21.08.01.024H Brass Water Intake 2"

Fischer Panda 2" Brass Grated Thru-Hull Water Intake Fitting (21.08.01.024H)

The Fischer Panda 21.08.01.024H is a high-capacity, marine-grade 2-inch brass grated thru-hull raw water intake fitting. Engineered for large-displacement Fischer Panda marine diesel generators and main propulsion auxiliary cooling circuits, it provides a high-volume water supply while keeping floating marine debris, plastic waste, and seaweed out of the intake plumbing.

Constructed from heavy-walled, corrosion-resistant cast brass, the fitting features a low-profile outer scoop head with an integrated cast/milled strainer grid across the inlet face. The body is machined with a 2" BSP/NPT external thread and includes a heavy brass retaining locknut to ensure a watertight, structural hull pass-through capable of withstanding severe hydrodynamic stress.

Key Features

• High-Flow 2" Throughput: Provides maximum raw water flow for high-output marine generator heat exchangers and central cooling loops.

• Integrated Intake Strainer Grate: Milled/cast outer grid blocks large debris at the hull line without creating significant hydrodynamic restriction.

• Corrosion-Resistant Marine Brass: Heavy-gauge brass construction resists dezincification and galvanic corrosion in submerged saltwater environments.

• Standard 2" Male Thread: Directly threads into standard 2" marine seacocks, ball valves, and raw water strainers.

• Included Flange Locknut: Comes equipped with a heavy brass locknut to clamp securely against backing blocks and hull layups.
