Mastervolt CombiMaster 24/2000-40 (230V) Inverter / Battery Charger
The Mastervolt 35022000 (Model: CombiMaster 24/2000-40) is a compact, heavy-duty marine/industrial 24V sine wave inverter and automatic multi-stage battery charger. Delivering a pure sine wave output of 2000 VA (1600 W continuously at 40°C) and an integrated 40 A 3-stage+ battery charger, it provides seamless AC power management for onboard 230 V 50/60 Hz appliances from a 24 V battery bank.
Featuring an ultra-fast 30 A automatic transfer switch, the CombiMaster switches instantaneously between shore/generator power and battery inverter mode without interrupting sensitive electronics. Built-in MasterBus, CZone, and NMEA 2000 communication interfaces allow complete integration into modern marine digital switching and monitoring networks.
Key Features
-
Pure Sine Wave Output: Provides clean, hum-free AC power for sensitive marine navigation, entertainment, and refrigeration electronics.
-
Smart 3-Stage+ Battery Charger: Delivers 40 A of safe, temperature-compensated charging compatible with AGM, Gel, Flooded, and Lithium-Ion (LiFePO4) chemistries.
-
Integrated 30 A Transfer Switch: Seamlessly toggles AC loads between shore power, generator, and inverter output with zero drop-out time.
-
Network Compatible (MasterBus / CZone / N2K): Plug-and-play communication support for system monitoring, remote control panels, and digital switching backbones.
Specifications
| Feature | Specification |
| Manufacturer / Brand | Mastervolt |
| Part Code / SKU | 35022000 |
| Series | CombiMaster |
| Nominal DC Voltage | 24 V DC (19-32V DC Operating Range) |
| Continuous Power Rating (40°C) | 1600 W (2000 VA) |
| Peak Surge Rating | 3000 W (1.5 seconds) |
| AC Output Voltage / Frequency | 230 V AC (± 2%) / 50/60 Hz (Selectable) |
| Output Waveform | Pure Sine Wave (THD < 3%) |
| Maximum Battery Charger Output | 40 A DC at 28.8V |
| Charge Algorithm | 3-Stage+ (Bulk, Absorption, Float) + Custom Li-Ion Profile |
| AC Input Voltage Range | 170-280 V AC |
| Integrated Transfer Switch | 30 A (Fast automatic relay switch) |
| Efficiency (Inverter Max) | ≥ 93% |
| No-Load / Standby Consumption | < 30 W (Normal) / < 2 W (Energy Save Mode) |
| Communication Interfaces | MasterBus, CZone, NMEA 2000 (via adapter) |
| Cooling Method | Variable Speed Temperature-Controlled Fan |
| Operating Temperature Range | -25°C to +60°C (Derating above 40°C) |
| Dimensions (H * W * D) | 371 mm * 284 mm * 152 mm (14.6'' * 11.2'' * 6.0'') |
| Weight | 6.9 kg (15.2 lbs) |
| Ingress Protection Rating | IP23 (Vertical Mount) |
| Compliance / Approvals | CE, E-Mark, IEC 62109-1, IEC 62109-2, EN 60945 |
