Mastervolt 50212629 25uF 475V Capacitor

Mastervolt 25µF 475V Capacitor Cable Kit Class B 60Hz (P15000i PMS)

The Mastervolt 50212629 is a genuine OEM capacitive service and maintenance kit engineered specifically for the P15000i PMS (Permanent Magnet System) marine marine generator series. Designed for 60Hz marine/commercial power grid configurations, this kit includes a high-grade 25 microfarad (μF), 475V AC Class B motor run / excitation capacitor fitted with pre-terminated, heat-resistant marine wire leads and connection terminals.

The capacitor plays a critical role in stabilizing excitation voltage, filtering harmonic distortion, and maintaining steady AC output under varying inductive electrical loads on the generator's inverter/stator assembly. Built to Class B operating standards (10,000 hours operating life rating at 85°C), it is supplied with an integrated mounting stud and sealed insulation leads for reliable operation in hot engine room compartments.

Key Features

• Direct OEM Replacement: Form-fit-function match for the primary excitation/run capacitor assembly in Mastervolt / Whisper Power P15000i PMS generators.

• Class B Rated Longevity: Certified to EN 60252-1 Class B standards, providing a continuous operating lifespan rating of up to 10,000 hours.

• Pre-Assembled Marine Cabling: Includes high-temperature, tinned copper wiring with insulated quick-connect spade terminals to prevent wiring faults during generator servicing.

• Self-Healing Dielectric Film: Polypropylene film construction prevents catastrophic shorting in the event of minor transient voltage spikes.

Specifications
