Mastervolt 70405010 Remote APC Control Panel 230V

Mastervolt 70405010 Remote APC (AC Power Control) Panel 230V

The Mastervolt 70405010 (Model: Remote APC) is a specialized remote control and monitoring panel engineered for 230V AC Mastervolt Mass Combi inverter/charger systems. Designed to provide localized management of shore power and generator feeds, the APC allows operators to track AC line dynamics and prevent shore power breaker trips via dynamic AC current limiting (Power Sharing).

The control panel features real-time visual displays for incoming AC voltage, current consumption, and shore line fuse thresholds. By setting the shore breaker limit directly on the panel dial, the Mass Combi automatically adjusts its internal battery charger power draw, ensuring total boat load never exceeds the available dockside circuit capacity.

Key Features

• Integrated Power Sharing: Adjusts maximum incoming AC current draw on-the-fly to prevent dockside circuit breakers or small generators from overloading.

• Live AC System Readout: Displays real-time AC voltage, power consumption, and active fuse limits.

• Power Limit Indicator: Visual status LED alerts when total boat consumption reaches the maximum set power-sharing threshold.

• Plug-and-Play Kit: Ships complete with a 6-meter modular communication cable and hardware for surface/flush panel mounting.
