Mastervolt 77010050 MasterView Read-out Display

Mastervolt MasterView Read-out Remote Display Panel (77010050)

The Mastervolt 77010050 MasterView Read-out is a compact, remote monitoring panel engineered to provide clear visual status readouts for Mastervolt battery chargers, Mass Combi inverter/chargers, and MasterBus power systems. Designed for flush panel mounting at the helm, nav station, or living quarters, it displays key battery performance metrics—including state-of-charge percentage, voltage, and charge/discharge current—without requiring access to the main power bay.

Equipped with a high-visibility 6-LED bar array, the MasterView Read-out alerts operators to incoming AC power availability, charge phase progression (Bulk, Absorption, Float), and active battery/system error faults. Connecting directly via a single MasterBus communication cable, it draws negligible operational power from the network while offering straightforward plug-and-play installation across vessel and vehicle management systems.

Key Features

• Instant System Status LEDs: Multi-color LEDs provide immediate visual feedback on AC supply status, charger state, and system alarms.

• Single MasterBus Cable Connectivity: Data and control power are supplied via a single MasterBus RJ45 network cable, simplifying installation.

• Compact Flush Mount Footprint: Sleek, low-profile bezel design integrates cleanly into modern vessel helms, control consoles, and RV interiors.

• Low Power Consumption: Ultra-low standby current draw prevents battery drain during extended off-grid periods.

Specifications
