Novaris SSP6A-26-G 26V Signal Surge Protector

Novaris SSP6A Slimline Series 26V Signal Surge Protector

The Novaris SSP6A-26-G is an ultra-slim, high-capacity signal and process loop surge protective device (SPD) designed to shield sensitive industrial control equipment, telemetry channels, PLC inputs, and marine signal networks against high-voltage transients, lightning strikes, and induced inductive surges.

Featuring an ultra-compact 6mm DIN-rail footprint, the SSP6A-26-G utilizes a hybrid multi-stage protection architecture comprising primary gas discharge tubes (GDT) alongside fast-acting semiconductor clamping diodes. Rated for a maximum continuous operating voltage of 26V DC and a high pass-through load current of up to 6A, it provides robust protection for 24V DC instrument loops, RS485 data lines, and power-fed sensor circuits without introducing high inline resistance.

Key Features

• Ultra-Slim 6mm Footprint: High-density DIN-rail packaging maximizes enclosure space in control panels and terminal junction boxes.

• Hybrid Multi-Stage Protection: Combines high-current GDT primary protection with precise silicon clamping for rapid response time (< 1 ns).

• High 6A Load Rating: Supports higher continuous loop currents than standard signal SPDs, making it ideal for powered sensor loops and auxiliary DC feeds.

• Vibration-Resistant Screw Terminals: Provides secure wire terminations suited for industrial control cabinets, transport systems, and engine room enclosures.

• Universal DIN Rail Mounting: Snaps directly onto standard 35mm Top-Hat DIN rail with automatic earthing contact via the DIN clip.
