Scanstrut TBH-10 Multi-Cable Bulkhead Seal

Scanstrut TBH-10 Multi-Cable Through-Bulkhead Seal

The Scanstrut TBH-10 is an IP68-rated multi-cable through-bulkhead seal engineered to pass up to 10 cables (up to ∅ 7mm each) through decks, bulkheads, or transom walls without requiring cable connector disassembly. Purpose-built for high-density marine instrument clusters, flybridge consoles, and radar arch cable entries, it provides an airtight, watertight seal around multiple lines simultaneously.

Featuring a high-grade aluminum frame with a corrosion-resistant marine finish and an engineered elastomeric seal, the TBH-10 utilizes a compression-fit design. As the outer compression plate is tightened, the elastomeric insert conforms around each cable profile, strain-relieving the lines and shielding the vessel interior against water ingress, fuel fumes, and chafe damage.

Key Features

• 10-Cable High-Density Routing: Routes up to 10 individual marine cables through a single compact bulkhead cutout.

• No Connector Removal Required: Allows pre-terminated factory cable connectors (NMEA 2000, Ethernet, VHF PL259, transducer plugs) to pass intact prior to sealing.

• 100% Watertight IP68 Protection: Tightly compresses around cable jackets to form an IP68 submersion-proof barrier.

• Integrated Cable Strain Relief: Prevents wire fatigue and connector strain caused by vessel vibration and cable weight.

• UV & Salt-Resistant Construction: Anodized aluminum body and marine-grade elastomeric bung withstand long-term UV radiation and salt spray.
