SunWare - Solar Panel TX-Series TX 12039 38 Wp

SunWare - Solar Panel TX-Series TX 12039 38 Wp

Pre order

$ 768.04 USD
$ 768.04 USD
Sale Pre Order
Shipping calculated at checkout.

Description

The slim module TX 12039 with 38Wp is intended for use on wind dress or other textile fabrics.

On the long sides 4 Tenax tops for easy attachment are inserted. The attached bases are screwed into the textile fabric, then snap on the module - Done.
  • 38.0 Wp Power
  • 2.20 A max. charging current
  • 9-11 Ah daily yield
  • 873.0 x 431.0 x 6.0 mm
  • seawater-tight cable plug
  • seawater-tight cable socket
  • 10m UV-resistant cable
  • Textile edge with Tenax fasteners
  • Tenax bases enclosed

Technical Data

Name Value Unit
Pmax 38.0 Wp
Imax 2.00 A
Umax 19.00 V
Uoc 22.8 V
Isc 2.20 A
no. of cells 36 pcs.
Cell sizes 39.0 x 156.0 mm
Laminate ETFE/EVA/ETFE
Length 873.0 mm
Width 431.0 mm
Name Value Unit
Textile edging width 46mm
Sys. Voltage 12.0 V
back plate 3.0mm Sandwich
Cable outlet on frontside
Cable 2 x 1.5 mm²
Cable length 0.4 m
Color weiss/white
Package Einzelkarton/sngl. box
Weight net 2.2 kg
Weight gross 5.4 kg
